XPS vs cement tile backer boards: how do they compare?

Insutile® News

Both boards give tiles a flat, rigid surface. They differ in weight, in how they are cut, in how they handle water and in whether they insulate.

A bathroom with large beige tiles on the walls and floor, a tall frosted window, a wall-hung timber vanity with a white basin and a backlit mirror
Home/News/XPS vs cement tile backer boards: how do they compare?

The short answer: an XPS tile backer board is 7× lighter than cement board, is cut with a utility knife, has a core with a water absorption of 0.1 % or less and insulates the surface behind the tiles. Cement board is denser and resists impact better. Both give tiles a flat, rigid surface, and in showers both are covered with a waterproofing membrane in most cases.

The comparison below covers weight, cutting, water, insulation, tiling and fixing. The figures for the XPS board are those of Insutile® Build Board.

What are the two boards made of?

A cement board is a thin, dense panel of Portland cement reinforced with fibres.

An XPS tile backer board has a core of closed-cell extruded polystyrene (XPS) foam. On an Insutile® board, a fiberglass mesh and a cement layer are applied to both faces of the core. The cement faces take the tile adhesive.

How much does each board weigh?

A cement board of 600 × 1200 mm at 12.5 mm weighs about 22 kg. An Insutile® Build Board of the same size and thickness weighs about 3 kg, so it is 7× lighter than cement board.

One person can carry a 3 kg board up a staircase, hold it against a wall and fix it. A cement board of that size is usually handled by two people when it is fixed to a wall.

How is each board cut?

Insutile® boards with the Regular Coat finish are scored with a utility knife and snapped. Shaped cuts are made with a fine-tooth saw. Boards with the Dual Coat · Patterned finish may need power tools.

Cement board can be scored and snapped for straight cuts. Openings and shaped cuts need a saw or a grinder with a diamond blade, which produces silica dust that has to be controlled and cleaned up.

Weight and cutting account for most of the difference in site labour. Labour on the boarding stage can fall by up to 50 %, depending on the room, the access and the substrate. The detail is in how Insutile® boards reduce installation time and labour.

How does each board handle water?

Cement board is water-resistant, not waterproof. It is not damaged by water, but it is porous, so it absorbs moisture and can pass it to the structure behind.

The closed-cell XPS core of an Insutile® board has a water absorption of 0.1 % or less (EN 12087). It does not swell or rot if moisture reaches it.

In showers, a waterproofing membrane is applied over the boards and joints in most cases. The difference is in what happens if moisture gets past the membrane. A cement board absorbs it. The XPS core takes up 0.1 % or less and is not harmed. The build-up for a shower enclosure is in tile backer board for showers.

Water droplets beading on the glossy surface of a pale grey tile, next to a tile joint
The substrate behind the tiles has to cope with any moisture that gets past the tile joints.

Which board insulates?

The XPS core is an insulation material. Insutile® boards have a thermal conductivity of 0.034 W/mK or less (ASTM C518). A 20 mm board has a thermal resistance of about 0.59 m²K/W, and a 50 mm board about 1.47 m²K/W. Cement board is dense and adds very little thermal resistance at backer board thicknesses.

On a cold wall, insulation directly behind the tiles keeps the tiled surface warmer. Under underfloor heating, the board limits downward heat loss, so more of the output goes into the room. See insulation boards under underfloor heating and the article on thermal performance.

How are the boards tiled and fixed?

Tiles are laid in a C2 class tile adhesive on both materials. On an Insutile® board the adhesive is applied directly to the cement face, without priming. A cement board is primed where its manufacturer requires it.

Insutile® boards are fixed with screws and fixing washers at 300 mm centres across the board and 150 mm at edges and joints. The washers are supplied with every board. The adhesive and the fixing method are chosen to suit the substrate or structure. The steps are in how to install Insutile® Build Board.

How do the two boards compare side by side?

CriterionCement boardInsutile® Build Board
Weight, 600 × 1200 mm at 12.5 mmAbout 22 kg.About 3 kg.
CuttingScored for straight cuts. Saw or grinder for openings.Utility knife (Regular Coat).
WaterWater-resistant but porous. Absorbs moisture.Water absorption ≤ 0.1 % (EN 12087).
Waterproofing in showersMembrane over the boards.Membrane over the boards and joints in most cases.
InsulationVery little at backer board thicknesses.λ ≤ 0.034 W/mK (ASTM C518).
Impact and loadDense and hard, with the higher impact resistance.Compressive strength ≥ 300 kPa (EN 826).
TilingC2 tile adhesive, primed where the manufacturer requires it.C2 tile adhesive on the board face, without priming.
FixingAs the manufacturer specifies.Screws and fixing washers at 300 mm centres. Chosen to suit the substrate or structure.

How do the costs compare?

Cement board usually costs less per square metre as a material. The installed cost also includes the labour to carry, cut and fix the boards, the dust control and the handling of waste. The comparison is made on the finished wall or floor, not on the board alone.

Which board should be specified?

For bathrooms, showers, wet rooms, kitchens and floors with underfloor heating, an XPS board gives a lighter installation, a core with a water absorption of 0.1 % or less and insulation behind the tiles. Insutile® boards have a compressive strength of 300 kPa or more (EN 826) and are used under ceramic, porcelain and natural stone tiles.

Cement board is dense and hard. It remains an option where a surface takes hard knocks or heavy mechanical traffic.

A desk seen from above with three square tile samples, a white notebook, a yellow pencil, a brass ruler and a rolled drawing
The backer board is chosen at the specification stage, together with the tile and the build-up behind it.

What does the Insutile® range include?

Insutile® is the range of lightweight construction boards made by Insutech. Insutile® Build Board is the flat board for walls, floors and countertops. It is made in ten thicknesses from 4 to 80 mm, customisable if needed. The other products have their own sizes, and the thickness guide covers the choice.

The range also includes Insutile® Flex Board for curves, Insutile® Angle Board for internal and external corners and pipe boxing, Insutile® Shower Underlay for shower floors, Insutile® Trays and Niches for recesses and seats, Insutile® Easy Board as a pre-tiled insulation board, and the accessories for fixing, jointing and waterproofing. The boards are CE marked and backed by a ten-year warranty.

The products for each room are on the bathroom and wet-room solutions page. The role of the foam core is explained in why an XPS core suits tiled wet rooms. Other wall substrates are compared in tile backer board options for bathroom walls.

Frequently Asked Questions

How much lighter is an XPS board than cement board?

A 600 × 1200 mm Insutile® Build Board at 12.5 mm weighs about 3 kg, against about 22 kg for cement board of the same size. It is 7× lighter than cement board.

Is cement board waterproof?

Cement board is water-resistant, not waterproof. It is not damaged by water, but it is porous and absorbs moisture, so in showers a waterproofing membrane is applied over it.

Does an XPS board need a waterproofing membrane in a shower?

In showers, a waterproofing membrane is applied over the boards and joints in most cases. The closed-cell XPS core itself has a water absorption of 0.1 % or less (EN 12087).

Which of the two boards insulates?

The XPS board. Insutile® boards have a thermal conductivity of 0.034 W/mK or less (ASTM C518). Cement board adds very little thermal resistance at backer board thicknesses.

When is cement board used instead?

Where impact resistance is the main requirement. Cement board is dense and hard, which gives it the higher resistance to hard knocks.
